AD210AN

ad210an, high performance isolation amplifier, pdip, 5v, 50ma, analog devices

Rated 5 Rating 5 | reviews | Write a review

Price:: US $65.00~68.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	68.00 / Piece
400 ~ 1000 :	65.00 / Piece

PartNumber:: AD210AN

Brand:: Analog Devices - ADI | Pack: | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. JieHui's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-12-19

From Other Seller

Part Number:AD210AN
US $65.00 - 68.00
Quantity:

piece

Product Summary

The AD210AN is a low cost, high performance isolation amplifier. This three-port, wide bandwidth isolation amplifier is manufactured with surface-mounted components in an automated assembly process. The AD210AN combines design expertise with state-of-the-art manufacturing technology to produce an extremely compact and economical isolator whose performance and abundant user features far exceed those offered in more expensive devices. The AD210AN provides a complete isolation function with both signal and power isolation supplied via transformer coupling internal to the module. The AD210AN functionally complete design, powered by a single +15 V supply, eliminates the need for an external DC/DC converter, unlike optically coupled isolation devices. The true three-port design structure permits the AD210AN to be applied as an input or output isolator, in single or multichannel applications. The AD210AN will maintain its high performance under sustained common-mode stress. The applications of the AD210AN include Multichannel Data Acquisition, High Voltage Instrumentation Amplifier, Current Shunt Measurements and Process Signal Isolation.

Parametrics

AD210AN absolute maximum ratings: (1)Number of Pins: 30; (2)Isolation Voltage: 2.50 kV; (3)Slew Rate: 1.00 V/μs; (4)Supply Current: 50.0 mA; (5)Supply Voltage (DC): 5.00 V; (6)Mounting Type: Through Hole; (7)Packaging: Tube; (8)RoHS: Non-Compliant.
